產品描述
| TM 螺紋銑刀 |  | ||||||
| 型號 Type No. | D1直徑 Diameter | L1刃長 Flute Length | L3全長 O.A.L | D2柄徑 Shank Dia. | 刃數 Flute | 螺距 Pitch | M 螺牙 Thread Size |
| TM03007M4070 | 3.0 | 7.28 | 40 | 6 | 3 | 0.7 | M4 |
| TM03010M4070 | 3.0 | 10.08 | 40 | 6 | 3 | 0.7 | M4 |
| TM06014M8125 | 6.0 | 14.25 | 60 | 8 | 3 | 1.3 | M8 |
| TM06019M8125 | 6.0 | 19.25 | 60 | 8 | 3 | 1.3 | M8 |
| TM08020M12175 | 8.0 | 19.95 | 60 | 8 | 3 | 1.8 | M12 |
| TM08029M12175 | 8.0 | 28.7 | 75 | 8 | 3 | 1.8 | M12 |
| TM09020M12175 | 9.0 | 19.95 | 75 | 10 | 4 | 1.8 | M12 |
| TM09029M12175 | 9.0 | 28.7 | 75 | 10 | 4 | 1.8 | M12 |
| TM10027M14200 | 10.0 | 26.8 | 75 | 10 | 4 | 2.0 | M14 |
| TM10039M14200 | 10.0 | 38.8 | 100 | 10 | 4 | 2.0 | M14 |
| TM12027M16200 | 12.0 | 26.8 | 80 | 12 | 4 | 2.0 | M16 |
| TM12039M16200 | 12.0 | 38.8 | 100 | 12 | 4 | 2.0 | M16 |
| TM12031M18250 | 12.0 | 31 | 100 | 12 | 4 | 2.5 | M18 |
| TM12045M18250 | 12.0 | 43.5 | 100 | 12 | 4 | 2.5 | M18 |
| TM14034M20250 | 14.0 | 33.5 | 100 | 14 | 4 | 2.5 | M20 |
| TM14049M20250 | 14.0 | 48.5 | 100 | 14 | 4 | 2.5 | M20 |
| TM16041M24300 | 16.0 | 40.2 | 100 | 16 | 5 | 3.0 | M24 |
| TM16059M24300 | 16.0 | 58.2 | 120 | 16 | 5 | 3.0 | M24 |
